DRIVE AXLE SHAFT ASSEMBLY FOR DANA 35; PERFORMANCE REAR AXLE KIT; AXLE LENGTH 30.563"/29.04"; 5 X 4.5 LUG PATTERN; 27 SPLINE; INCLUDES LEFT AND RIGHT AXLES, BEARINGS, SEALS AND STUDS; 1541 MANGANESE; W/ C-CLIP; ABS READY - DOES NOT INCLUDE
TEN Factory - Precision Forged for Quality, Strength and Performance. All TEN Factory axles feature a 10-year replacement warranty! Front axles and two axle rear kits are black oxide coated. TEN Factory is the brand you can trust for the highest-quality engineered axle shafts and replacement kits. Built with the toughest materials, the wear-resistance of forged steel is heat-treated to produce durable axle shafts for your Jeep, car or truck. Buy with confidence knowing that the latest technologies in metallurgy, heat treating and CNC machining have produced an axle you can count on in the most difficult conditions.
Information:
REAR KIT-D35 1990-06 YJ/XJ/TJ 27SPL L&R
Application Summary:
| Year |
Make/Model |
| 1990-2001 |
Jeep Cherokee |
| 1990-1992 |
Jeep Comanche |
| 1993-1995 |
Jeep Grand Cherokee |
| 1990-1991 |
Jeep Grand Wagoneer |
| 1993 |
Jeep Grand Wagoneer |
| 1997-2006 |
Jeep TJ |
| 1989-1990 |
Jeep Wagoneer |
| 1990-1995 |
Jeep Wrangler |
| 1997-2006 |
Jeep Wrangler |
| Attributes |
| 136 |
5 x 4.5 |
| 2872 |
Black Oxide |
| 396 |
High Manganese 1541H |
| 704 |
27 |
| 7801 |
33.31 |
| ASIN |
B003TPSIHA |
| App/Model |
Dana 35 Standard |
| Axle Length |
33.31 |
| Axle Material |
1541 Manganese |
| Axle Shaft Spline Quantity |
27 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Coated Finish |
Black Oxide, Black Oxide |
| Country of Origin (Primary) |
US |
| Differential Case Design Type |
Dana 35, Dana 35 |
| Emission Code |
Legal US |
| GTIN |
00698231914380 |
| Harmonized Tariff Code (Schedule B) |
8708504110 |
| Hazardous Material Code |
N |
| Inboard Spline Quantity |
27, 27 |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| Outboard Spline Quantity |
27 |
| Position |
Rear, Rear |
| SDR Required Flag |
N |
| Shaft Length |
29.04 R, 30.563 L |
| Shaft Material |
1541 Manganese |
| Side |
Left and Right |
| Taxonomy |
Differential LD |
| Taxonomy A |
LD Differential |
| Taxonomy B |
Axle Shafts |
| Taxonomy C |
Axle Kits - Rear |
| Taxonomy D |
Left and Right |
| Warranty Time |
120 |
| Wheel Bolt Pattern Size |
5 x 4.5, 5 x 4.5 |
